Australian Broadband

Australian Broadband Networks

Team Compute enables you to access, build and own the local communication infrastructure of your neighbourhood.

You can be:

  1. Local Node - bridging nodes within a Local Mesh together.
  2. Edge Node - bridging Area Mesh with the wider internet.

Both roles are as simple as connecting your Mesh Node with to the broadband router on your site (either using an ethernet cable or through WiFi radio).

Campus network aims to provide a base upload speed of around 50Mbps (based on low cost 802.11n WiFi radios operating on a single 20 MHz channel with one antenna and 400ns guard interval).

Using a 1GByte as standard (approximate size of a 10 minute video with 1920x1080 resolution at 30 frames per second using advanced encoding (e.g. AV1) .

VOLUME in bytes SPEED in bits/second TIME in minutes:seconds
0.5 G 1 M 66:40
0.5 G 5 M 13:20
1 G 1 M 133:20
1 G 5 M 26:40
1 G 10 M 13:20
1 G 15 M 8:53
1 G 20 M 6:40
1 G 25 M 5:20

If you are offering resources to other Private Cyberspaces over the internet, then an internet UPLOAD bandwidth of at least 10Mbps is recommended.

If you CANNOT afford a Upload speed of 10Mbps

1. NBN

NBN is owned by the Commonwealth of Australia as a Government Business Enterprise.

NBN Residential Links

Type Download Upload
NBN 12 12Mbps 1Mbps
NBN 25/5 25Mbps 5Mbps
NBN 25/10 25Mbps 10Mbps
NBN 50 50Mbps 20Mbps
NBN 100/20 100Mbps 20Mbps
NBN 100/40 100Mbps 40Mbps
NBN 250 250Mbps 25Mbps
NBN 1000 1000Mbps 50Mbps

NBN Asymmetrical Links

Download Upload
100Mbps 40Mbps
1000Mbps - 500Mbps 50Mbps
250Mbps 100Mbps
500Mbps 200Mbps
1000Mbps 400Mbps

NBN Symmetrical Links

Range Increment
10Mbps - 100Mbps 10Mbps increments
100Mbps - 500Mbps 50Mbps increments
500Mbps - close to 1Gbps 100Mbps increments
Close to 1Gbps - close to 10Gbps 1000Mbps increments

In comparing between different NBN speed options, NBN like to use 10GB file for download and 1GB file for upload. The upload time required range from within 4 minutes to 3 hours!

Unfortunately, a lot of Australians are on the lower end of that range:

nbn_speeds
Numbers above in thousands as at Dec 2022 (Source: Statista)

2. Uniti

Owns the following wholesale broadband brands:

3. TPG

Owns the following wholesale broadband brands:

4. Vocus

Australian Internet Exchanges

1. IX Australia

https://internet.asn.au/services/peering/

2. Edge IX

3. Mega IX

Australian Campus Network

NBN's current bandwidth delivery model is extremely inefficient. Traffic between neighbours just a few METRES apart, have to travel to KILOMETRES through their local phone exchange to a POI further away, then from these POI to the Internet Service Provider's data centre which is even further away, then it reached the Cloud Platform and turns around and comes back through the same POI and same exchange to the neighbours.

click image below to expand

then on to data centre of the neighbours

Virtual Private Meshes can reduce the lost the prices of internet bandwidth by supplying massive amount of last-mile capacity to

helping the Australia

Australia has one of the most expensive bandwidth prices prices in the world

Private Cyberspace relies on Virtual Private Meshes to deliver "free" bandwidth although

Mesh Stations working to

DHCP Providers

As of 2024-0701, the following NBN providers supportsconnection via DHCP, making installing Ethernet Station as a router a simple plug and play experience.

  1. Activ8me Activ8me
  2. Aus Internet Aus Internet
  3. Aussie Broadband Aussie Broadband
  4. Belong Belong
  5. BorderNet BorderNet
  6. EscapeNet EscapeNet
  7. Future Broadband Future Broadband
  8. Go Internet Go Internet
  9. IPStar Broadband IPStar Broadband
  10. Optus Optus
  11. Origin Broadband Origin Broadband
  12. Launtel Launtel
  13. Leaptel Leaptel
  14. LightningIP LightningIP
  15. Southern Phone Southern Phone
  16. Superloop Superloop
  17. Skymesh Skymesh
  18. Telstra Telstra
